HR-202i Analytical Balance with Internal Calibration
The HR-202i is a high-precision analytical balance offering exceptional performance at an affordable price. This model features dual weighing ranges with 0.01mg semi-micro resolution, internal calibration capability, and comprehensive data management features suitable for regulated laboratory environments.
Dual Range Weighing Performance
The HR-202i provides two distinct weighing ranges to accommodate different precision requirements: a high-capacity range of 220g with 0.0001g resolution, and an ultra-precise range of 51g with 0.00001g (0.01mg) resolution. This dual-range capability allows users to maximize accuracy when weighing smaller samples while maintaining versatility for larger items.
Weighing Capacity and Resolution
| Unit |
Capacity × Resolution |
| Gram (g) |
220×0.0001 / 51×0.00001 |
| Milligram (mg) |
220,000×0.1 / 51,000×0.01 |
| Decimal Ounce (oz) |
7.4×0.00001 / 1.4×0.000001 |
| Troy Ounce (ozt) |
6.7×0.00001 / 1.3×0.000001 |
| Pennyweight (dwt) |
135×0.0001 / 27×0.00001 |
| Carat (ct) |
1050×0.001 / 210×0.0001 |
| Momme (mom) |
56×0.0001 / 11×0.00001 |
| Grain Unit (GN) |
3240×0.002 / 648×0.0002 |
| Tola (t) |
18×0.00001 / 36×0.000001 |
| Tael (TL) |
5.5×0.00001 / 1.1×0.000001 |
Performance Specifications
| Parameter |
Specification |
| Linearity |
±0.0002 / ±0.00003 g |
| Repeatability / Std Dev |
0.0001 / 0.00002 g |
| Stabilization Time |
Approx. 3.5 / 8 seconds |
| Sensitivity Drift (10°C – 30°C) |
±2ppm / °C (when automatic self calibration is not used) |
| Display Refresh |
5 times per second / 10 times per second |
| Percentage Min Div |
0.01%, 0.1% or 1% (auto prompt) |
| Counting Min Weight |
0.1 mg |
Key Features
- 0.01mg Semi-Micro Resolution
- User Friendly Operation with large, clearly marked keys
- Liquid Crystal Display with large, easy-to-read digits
- RS-232C Bi-directional Interface (Standard for "i" models)
- Windows Communication Tools Software
- GLP/GMP/GCP/ISO Compliance
- Balance ID Number
- Automatic Counting Accuracy Improvement
- Auto Power On Function
- Underhook Capability
- 5 Year Warranty
Data Management and Compliance
The balance supports comprehensive data management with Balance ID Number that is user specified and stored when power is off. GLP/GMP/GCP/ISO compliance features allow for effective balance management with data output to an AD-8121B printer or computer, including Date, Time, Balance ID number, Serial number, and Calibration data.
Automatic Counting Accuracy Improvement
Continuous recalculation of average piece weight ensures optimum count accuracy during parts counting operations.
Physical Specifications
| Dimension |
Metric |
Imperial |
| Overall Dimensions (W×D×H) |
217×442×316 mm |
8.54×17.4×12.24 in |
| Breeze Break Dimensions (W×D×H) |
164×148.5×251 mm |
6.45×5.84×9.88 in |
| Pan Size |
Ø 90 mm |
Ø 3.6 inches |
| Weight |
Approximately 8.0 kg |
Approximately 17.6 lb |
Operating Requirements
- Operating Temperature: 5°C to 40°C (41°F to 104°F), 85% RH or less (no condensation)
- Power: 100, 120, 220, 240 VAC (AC Adapter) 50 Hz / 60 Hz, 11 VA
Standard Accessories
- WinCT in CD-ROM
- Manual
- AC Adapter
External Calibration Mass (Optional)
200 g / 100 g / 50 g / 20 g
