4-decimal Balance

The A&D Apollo GF-324A initially does a self-diagnostic before performing an internal repeatability test without an external weight in < 1.5 minutes.

FEATURES:
Leveling Made Easy
• Level me prompt, turn on, screen blinks for 5 seconds to prompt user to level.
• Bright-bubble – Large, easy-to-see, front mounted spirit level with LED Illumination.
• Fly-thumbwheel is effortless & accessible allows ergonomic adjustment with anti-slip feet.

Simple User Interface
• Six straightforward keys – ON/OFF, CAL, MODE, SAMPLE, PRINT, REZERO.
• Reverse Backlit LCD is a large display with great B&W contrast provides excellent visibility.

Cleanable Robust Construction
• Stainless Steel Pan & Dust-plate can be easily removed for cleaning.
• “Click & Lift” detachable chamber & collapsible side doors that save on space.
• Die-cast Aluminum housing provides extra stability and durability.

Flexible Interface & Security
• Standard RS-232C & USB – Toggle between the Quick USB mode or Virtual COM mode
(bi-directional). A USB cable comes standard.
• Security Slot – Anti-theft lock (such as Kensington) to prevent loss

SPECIFICATIONS:
Capacity 320 g
Readability 0.1 mg (0.0001 g)
Pan Size Ø90 mm
Repeatability (std. deviation) 0.0001 g (200 g)
0.0002 g (300 g)
Minimum Weight (typical) 120 mg
Linearity ±0.0003 g
Stabilization Time (fast mode with good environment) Approximately 1.5 seconds (100 g)
Approximately 2 seconds (200 g)
Sensitivity Drift ±2 ppm/°C (10 to 30°C / 50 to 86°F, when automatic self calibration is OFF)
Operating Environment 5 to 40°C (41 to 104°F), 85% RH or less (no condensation)
Display Refresh Rate 5 times/sec, 10 times/sec or 20 times/sec
Units of Measure mg, g, oz, ozt, ct, mom, dwt, gr, pcs, %, SG (density mode), and a user-programmable unit
Counting Mode Minimum unit mass: 100 g
Number of samples: 5, 10, 25, 50 or 100 pieces
Percent Mode Minimum 100% reference mass: 0.0100 g
% of readability: 0.01%, 0.1% or 1% (depends on the reference mass stored)
Communications Interfaces RS-232C and USB
Applicable Calibration Weight Values 50 g, 100 g, 200 g, 300 g
External Dimensions 259 x 358 x 332 mm / 10.2 x 14.1 x 13.1 inches
