Circulating Chiller / Cooler

Combining operational excellence and technological expertise with an intimate understanding of customer needs, LabTech offers the H150-1500 recirculating water chiller to ensure accurate and constant cooling conditions for instrumentation.

The chiller is provided with a touchscreen display to monitor and control instrument temperature from 8-35°C and is designed to operate on 115V/60Hz with a standard 115V US plug for use with similar electrical requirements. It has a PID Temperature control mode to provide Temperature Stability at +/-0.1℃ with efficient compressor cooling. Cooling capacity for the unit is 1500W at 25℃ and is ideal for use with rotary evaporation, reflux extraction and AA/ICP applications. The H150-1500 has a pump capacity of 6.4L/min and a max pressure of 60psi for external circulation. The liquid circuit pressure is monitored and controlled via analog pressure indicator.

Furthermore, the unit is provided with a liquid level indicator for maximum safety of operations. The chiller has a built in drain to easily remove the liquid from the internal reservoir and water connections are located on the rear side.

SPECIFICATIONS:
Temp. Range: 8 to ~35°C
Temp. Stability: ±0.1°C
Temp. Control Mode: PID
Cooling Capacity: 1500W
Pump Flow: 6.4L/min
Elc: CUL
Outside: 27×15×23 in.H
Volts: Specify 115 or 230
Hertz: 50 or 60
