Pharmaceutical Refrigerator / Freezer

This Pharmacy refrigerator and freezer combination unit is designed with a variable speed compressor to deliver unparalleled temperature control. Safeguard your samples with superior temperature uniformity and recovery, even after frequent door openings. Monitor your vaccines though intuitive digital displays and protective alarms.

Champion sustainability with natural hydrocarbon refrigerants—which not only contribute to energy savings, but also foster a greener footprint. Elevate your medical cooling experience with an integrated solution that brings together innovation, performance, and precision.

SPECIFICATIONS:
Storage capacity (cu. ft): 13 Cu. Ft. Refrigerator / 3 Cu. Ft. Freezer
Door: Double Swing Solid Right Hinged Doors
Shelves (Frg/Frz): 3 adjustable, vented stainless steel shelves refrigerator / 1 fixed shelf freezer
Drawers (Frg/Frz): Non-applicable
Mounting and Installation: Leveling Legs
Interior lighting: 12V LED light bar (Refrigerator)
Airflow Management (Refrigerator): Forced draft air circulation (Refrigerator)
External probe access:Probe access port (3/8″) dia., 2 ea. (1 for Refrigerator/1 for Freezer)
Access control: Keyed door lock
General warranty: Two (2) years parts and labor warranty
Compressor warranty: Seven (7) years compressor warranty
Refrigerator Uniformity¹ (Cabinet air): +/-0.22°C
Refrigerator Stability² (Cabinet air): ±0.48°C
Refrigerator Maximum temperature variation: ±0.71°C
(Cabinet air)
Freezer Uniformity¹ (Cabinet air) ±0.69°C
Freezer Stability² (Cabinet air) ±1.14°C
Freezer Maximum temperature variation: ±1.95°C
(Cabinet air)
Energy Consumption (KWh/day): 3.73
Average Heat Rejection (BTU/hr): 5.25
Average Heat Rejection (BTU/hr): 746
Noise Pressure Level (dBA): 48 or less installed
Pull down time to nominal operating temp (Frg/Frz): 40 min / 165 min
Compressor: Variable speed (VSC), Refrigerator. Rated speed range: 1300-4000 rpm
Refrigerant: R600a n
Defrost (Refrigerator/Freezer): Cycle Optimized Zero-Energy / Auto Defrost
