Ramsbottom Carbon Residue Tester for Petroleum

Determines the `carbon residue' left after evaporation and pyrolysis of a sample oil in the Ramsbottom furnace, providing an indication of the deposit forming tendencies of fuels and guidelines for the processing of refinery products.

¦ Conforms to ASTM D524 and related specifications
¦ Microprocessor temperature control with digital display and overtemperature cut-off
Thermostatically controlled coking furnace for five samples. Castiron block type furnace reaches the standard test temperature of 550°C (1022°F) rapidly and controls with ±1°C stability. Microprocessor temperature control has °C/°F switchable digital setpoint and display. Operator and equipment are protected by an overtemperature control circuit which automatically interrupts power to the unit should block temperature exceed the programmed cut-off point. Communications software (RS232, etc.), ramp-to-set and other enhanced features are available as extra cost options. Contact your Koehler representative for information. Heavily insulated stainless steel cabinet with threelayer refractory top provides excellent heat retention.

SPECIFICATIONS:
Furnace Type: Cast iron block
Capacity: 5 coking bulbs
Maximum Temperature: 650°C (1200°F)
Controller Sensitivity: ±1°C (± 2°F)
Heater: 0-2400W, ceramic band heater
