Film Thickness Gauge

FEATURES:
Coating thickness gauge with reliable results and easy to use
Intergrated probe
Automatically turns on and off
Operation with one hand and one button
Only one function key
Optimal readability - large numbers
Can be read in the dark and in direct sunlight - backlit LCD
For everyday use - ergonomic design with recessed grip
Polished ruby measuring head tip protects the measuring probe and the surfaces to be measured

SPECIFICATIONS:
Measuring Principle: Magnetic-Flux/Hall Effect ref Fe
Probe Type: Integrated or - optional - Cable Probe with 1 m cable
Measuring Ranges: Fe: 0.0 - 3000 µm
Metric System µm/mil: Yes
Measuring Interval: Single measurement: 850 ms
Display Metric: From 0.0 - 999 in µm, from 1000 µm in mm
Resolution: 1 µm in the range up to 999 µm, 0.01 mm in the range from 1 mm
Minimum Measuring Area: Ø 25mm
Minimum Curvature: Convex: 5 mm; Concave: 25 mm
Minimum Substrate Thickness: Fe: 0.2mm
Display: Graphic-LCD
