HI6000 Series Multiparameter Modular System
The HI6000 multiparameter modular system is a totally flexible benchtop meter platform that is customizable to a user's laboratory measurement and application needs. Hanna offers four different measurement modules for pH/ORP, pH/ORP/ISE, DO, and EC. Together with appropriate sensors, the meter provides quick and reliable measurement displayed on the large touch screen display.
Display and Interface
The benchtop unit features a 7-inch color capacitive touch screen with 800 x 480p resolution. The multi-touch display supports video playback and data plotting. A status area runs continuously across the top of the LCD screen, displaying current time, date, network connectivity, device connectivity, storage space availability, and current logged-in user information. The interface includes stability indicators, active measurement profiles, logging status icons, measurement readings, probe and calibration information, and active module status.
System Configuration
Multiple screen configurations allow up to 3 measurements to be shown simultaneously. View options include single-parameter, dual-parameter, and triple-parameter screens that can be mixed and matched. The system menu provides control over user accessibility, system and connectivity configuration, access to logged data, reports, and video-supported help.
User Management
The system supports up to 9 users plus the default administrator account. Standard user accounts can be created and configured for specific accessibility. Only the user who generated data has access to logs created by that user. Administrators can create and manage accounts from the Account Management Screen.
System Settings
Configurable system options include Time, Date, Language, Meter ID, Decimal Separator, Backlight Saver, Audible signals, Startup Tutorial, Reset User, and Factory Settings restore (admin function only).
Measurement Capabilities
Module Options
Up to three measurement modules may be easily installed into the HI6000 housing in any combination of the available modules. The plug-and-play design allows effortless installation and module swapping. Sensors are purchased separately.
| Module |
Sensor Type |
Details |
| HI6000-1 |
pH/ORP |
For ORP (redox) measurements a separate sensor is required. |
| HI6000-2 |
pH/ORP/ISE |
Features Incremental Methods for Ion Selective Electrode (ISE) applications. |
| HI6000-3 |
EC |
Supports the measurement of high purity water used in the pharmaceutical industry. The application includes meter verification, cell validation applications and the module is programmed for the three stages of the USP <645> bulk water analysis. Once a stage is met a report can be generated and saved. |
| HI6000-4 |
DO |
Supports dissolved oxygen applications for batch analysis of multiple samples: Oxygen Uptake Rate (OUR), Specific Oxygen Uptake Rate (SOUR), Biological Oxygen Demand (BOD). Reports are available for analysis records. |
Data Logging and Connectivity
Logging Features
- User controlled data log collection of at least 1,000,000 data points (with time and date stamp)
- Logging types: manual, automatic, autohold
- Sample ID for manual and autohold data
- 50,000 maximum records per file
- Automatic logging intervals: 1, 2, 5, 10, 30 s; 1, 2, 5, 10, 15, 30, 60, 120, 150, 180 min.
- Sample ID: Incremental mode or manual
Connectivity Options
- Transfer logged data to a USB thumb drive
- Log files include measurements and calibration data (as .CSV file)
- FTP and email for log export via ethernet and Wi-Fi connection
- Download logs using the benchtop's embedded web server
- USB type A (2 ports) for USB drive, printer, and keyboard
- USB type C (1 port) for USB drive and PC connection
- Ethernet port
- RS232 for connecting peripherals
Log files can be shared via USB, FTP, web server and email. Data can be viewed tabulated (complete with date, time, and notes), or plotted as graph. Log details include user and profile name, instrument name and serial number, channel, lot information, as well as GLP data.
View Configuration Options
Users can select preferred display configurations based on parameter type:
Basic View
Displays the measured value, measurement unit, and temperature source.
Simple GLP View
Displays last calibration date and time, Offset value, average slope (Avg. Slope), and electrode condition (Condition).
Full GLP View
Displays electrode symbol, used buffers trays together with calibration date, time, and temperature probe status.
Graph View
The measured value is plotted as a graph and all graph details can be viewed by using zoom and pan options for both axes and parameters.
Table View
Measured values are displayed tabulated (complete with date, time, and notes made during logging). The newest data is displayed on the top of the table.
Measurement Setup Configuration
Reading Options
Customize measurement options such as Parameter, Resolution, Stability Criteria, Reading Mode.
Temperature Settings
Customize temperature options such as Automatic or manual temperature Source, °C, °F, or K temperature Unit, Manual Temperature input, Isopotential Point.
Alarm Configuration
Set high and low threshold limits for measured parameters. When the parameter is enabled and the measurement exceeds the high-limit value or drops below the low-limit value, the alarm is triggered and will appear on the message banner along with an audible alarm (if Alarm Beepers is enabled).
Profiles
A profile is a sensor setup complete with required measurement unit, temperature unit, display preference, and alarm threshold options. Once saved the profile can be loaded for applications that require similar configurations. Application-specific profiles allow quick and direct measurement without the need to update the sensor and system settings.
HI6000-1 pH/ORP Module
Parameters and Modes
HI6000-1 module measures pH and mV. Reading modes include Direct and Direct/Autohold.
Recommended Probes
- HI1131B Recommended Refillable combination pH electrode
- HI7662-TW Recommended Stainless steel Temperature probe
HI1131B is a glass body, double junction, refillable pH electrode with an indicating sensor made of High Temperature (HT) glass. The double junction reference and HT glass design allow the HI1131B to be used in a wide variety of applications including samples with metals and elevated temperatures. Probe connection to the unit is secured through a galvanically isolated BNC connection.
HI7662-TW stainless steel temperature probe allows the meter to automatically temperature compensate (ATC) pH measurements.
Specifications: HI6000-1 pH/ORP Module
| Parameter |
Specification |
| pH Range |
-2.0 to 20.0 pH; -2.00 to 20.00 pH; -2.000 to 20.000 pH |
| pH Resolution |
0.1 pH; 0.01 pH; 0.001 pH |
| pH Accuracy |
±0.1 pH; ±0.01 pH; ±0.002 pH (±1 last significant digit) |
| mV Range |
−2000.0 mV to 2000.0 mV |
| mV Resolution |
1 mV; 0.1 mV |
| mV Accuracy |
±0.2 mV ±1 last significant digit |
| Temperature Range |
-20.0 to 120.0 °C; -4.0 to 248.0 °F; 253.2 to 393.2 K |
| Temperature Resolution |
0.1 °C / 0.1 °F / 0.1 K |
| Temperature Accuracy |
±0.2 °C / ±0.4 °F / ±0.2 K |
| Relative mV Offset Range |
±2000.0 mV |
| pH Calibration Points |
Up to 5 |
| Calibration Type |
Automatic; Semiautomatic; Manual |
| Standard Buffers |
Hanna and NIST pH 1.68, 3.00, 4.01, 6.86, 7.01, 9.18, 10.01, 12.45 |
| Custom Buffers |
Up to 5 |
| Custom Group |
Up to 5 |
| Temperature User Calibration |
Single point, adjustable; Isopotential point: -2.000 to 20.000 pH |
HI6000-2 pH/ORP/ISE Module
Parameters and Modes
HI6000-2 module measures pH, mV, Rel. mV, and ISE. Modes include Direct, Direct/Autohold, Known Addition, Known Subtraction, Analyte Addition, and Analyte Subtraction.
ISE Measurement Features
The HI6000 allows for calibration and readings in choice of concentration units. The choices of concentration units include ppt, g/L, mg/mL, ppm, mg/L, μg/L, ppb, μg/mL, mg/mL, M, mol/L, mmol/L, %w/v and a user-defined unit.
In addition to pH or ORP measurement, HI6000-2 module also features ISE measurement and Incremental Methods for Ion Selective Electrode applications. Known Addition, Known subtraction, Analyte Addition and Analyte Subtraction are versatile methods for the measurement of ions in aqueous samples from environmental, agricultural, industrial, biotechnical, pharmaceutical, food, wastewater, drinking water. These methods offer stepwise guidance for ion analysis and are great for complex or high ionic strength samples as the electrodes remain immersed throughout the process, so analysis is faster and more accurate.
Recommended Probes
- HI1131B Recommended Refillable combination pH electrode
- HI7662-TW Recommended Stainless steel Temperature probe
- Hanna Ion Selective Electrodes
Specifications: HI6000-2 pH/ORP/ISE Module
| Parameter |
Specification |
| pH Range |
-2.0 to 20.0 pH; -2.00 to 20.00 pH; -2.000 to 20.000 pH |
| pH Resolution |
0.1 pH; 0.01 pH; 0.001 pH |
| pH Accuracy |
±0.1 pH; ±0.01 pH; ±0.002 pH (±1 last significant digit) |
| mV Range |
−2000.0 mV to 2000.0 mV |
| mV Resolution |
1 mV; 0.1 mV |
| mV Accuracy |
±0.2 mV ±1 last significant digit |
| ISE Range |
1 x 10-6 to 9.99 x 1010 concentration |
| ISE Resolution |
1; 0.1; 0.01; 0.001 concentration |
| ISE Accuracy |
±0.5% |
