MC-100KS Mass Comparator
The MC-100KS is a high-performance mass comparator featuring extended resolution for precision weighing applications. This balance displays weighing results with an extra decimal place beyond what is typically found in balances of the same capacity, enabling measurements of minute weight changes with heavy objects or containers. The MC-100KS features a special stabilizing filter to cope with environmental disturbances such as drafts and vibrations, ensuring smooth and accurate mass comparison.
Technical Specifications
| Parameter |
Value |
| Weighing Capacity |
101 kg |
| Minimum Weighing Value |
0.1 g |
| Repeatability (Standard Deviation) |
0.2 g (for 100 kg)
0.1 g (for 60 kg) |
| Linearity |
±2 g |
| Sensitivity Drift (10 to 30°C / 50 to 86°F) |
±6 ppm / °C |
| Accuracy Immediately After Internal Calibration |
±10.0 g |
| Operating Environment |
5°C to 40°C (41°F to 104°F), 85%RH or less (no condensation) |
| Display Refresh Rate |
5 times/second or 10 times/second |
| Weighing Pan Size |
386 x 346 mm |
| External Dimensions |
Display unit: 260 (W) x 164 (D) x 202 (H) mm
Platform: 346 (W) x 443 (D) x 130 (H) mm
Cable length: 3 m |
| Net Weight |
Approx. 18 kg |
| Power Consumption |
Approx. 15 VA (supplied to the AC adapter) |
| Standard Interface |
RS-232C |
Display Modes
The MC-100KS supports multiple weighing units and operational modes including gram, kilogram, ounce, pound, pound-ounce, troy ounce, metric carat, momme, pennyweight, grain, counting mode, percent mode, density mode, and a user-programmable unit.
Key Features
- Enhanced stabilizing filter for accurate measurement under varying environmental conditions
- Simplified calibration using internal mass with one key press
- Super Hybrid Sensor technology
- Internal calibration capability
- VFD display
- GLP compliant
- Percentage function
- Comparator function
- Data memory function
- Clock and calendar
- Auto power ON/OFF
- Counting with ACAI
- Accumulation function
- Quick USB compatibility
- IP65 rating (optional)
- Underhook capability
Applications
The MC-100KS is suitable for a variety of precision weighing applications:
Management of Liquids
- Resist inks on flat panels (glass)
- Coating materials on silicon wafers
- Moisture contents of catalysts
- Solder pastes and sealing materials on electronic parts
- Resins used for LED lenses
- Surface materials on optical lenses
- Grease in miniature bearings for hard disks
Management of Powders
- Medicines in pharmaceutical manufacturing – from full flow to minute flow
- Discharges (losses in weight) from feeders
- Wear volumes of metallic materials
- Cutting dust (contaminants) left on mechanical parts
- Particles caught by filters
Management of Gases
- Fill ration of hydrogen gas
- Gasified components
Production Line Weighing
- As precision check-weighing sensors with wider ranges
Available Options
| Option Code |
Description |
| GP-04 |
Comparator output with a buzzer/RS-232C/Current loop output (only one of GP-04, GP-06 or the standard RS-232C can be used) |
| GP-06 |
Analog output/Current loop output (only one of GP-04, GP-06 or the standard RS-232C can be used) |
| GP-07 |
5-meter extension cable (factory-installed option) |
| GP-12 |
Animal weighing pan (optional) |
| GP-21 |
Underhook |
| GP-22 |
AD-8121B printer support |
Compatible Accessories
- AD-1602-E2: Calibration masses, OIML class E2 (selectable from 50 g to 20 kg)
- AD-1602-F1: Calibration masses, OIML class F1 (selectable from 50 g to 20 kg)
- AD-1682: Rechargeable battery unit
- AD-1683: Static eliminator
- AD-1684: Electrostatic fieldmeter
- AD-1687: Weighing environment logger
- AD-1688: Weighing data logger
- AD-1689: Tweezers for calibration mass
- AD-1691: Weighing environment analyzer
- AD-8121B: Compact printer
- AD-8526: Serial/Ethernet converter
- AD-8527: Quick USB adapter
- AD-8920A: Remote display
- AD-8922A: Remote controller
- AX-SW128: Foot switch
- AX-USB-25P: Serial/USB converter
