16 Cu. Ft. Pharmacy Refrigerator and Freezer Combo Unit
These Pharmacy refrigerator and freezer combination units are designed with a variable speed compressor to deliver unparalleled temperature control. Safeguard your samples with superior temperature uniformity and recovery, even after frequent door openings. Monitor your medical equipment though intuitive digital displays and protective alarms. Champion sustainability with natural hydrocarbon refrigerants—which not only contribute to energy savings, but also foster a greener footprint. Elevate your medical cooling experience with an integrated solution that brings together innovation, performance, and precision.
Model Number
PH-ABT-HC-RFC-16A
Storage Capacity
- 13 Cu. Ft. Refrigerator / 3 Cu. Ft. Freezer
Key Features
- Double Swing Solid Right Hinged Doors
- 3 adjustable, vented stainless steel shelves refrigerator / 1 fixed shelf freezer
- 12V LED light bar (Refrigerator)
- Forced draft air circulation (Refrigerator)
- Probe access port (3/4") dia., 2 ea. (1 for Refrigerator/1 for Freezer)
- Cabinet is foamed-in-place with EPA compliant high density urethane foam
- Bioscience Grey powder coated canopy, white textured chamber exterior
- Keyed door lock
Performance Specifications
| Parameter |
Value |
| Refrigerator Uniformity¹ (Cabinet air) |
+/-0.22°C |
| Refrigerator Stability² (Cabinet air) |
±0.48°C |
| Refrigerator Maximum temperature variation (Cabinet air) |
±0.71°C |
| Freezer Uniformity¹ (Cabinet air) |
±0.69°C |
| Freezer Stability² (Cabinet air) |
±1.14°C |
| Freezer Maximum temperature variation (Cabinet air) |
±1.95°C |
| Energy Consumption (KWh/day) |
3.73 |
| Average Heat Rejection (BTU/hr) |
746 |
| Noise Pressure Level (dBA) |
48 or less installed |
| Pull down time to nominal operating temp (Frg/Frz) |
40 min / 165 min |
Notes on Performance Data: Performance data acquired at 22°C ambient, 5°C/-33°C nominal set points in an empty cabinet with shelves using air probes, during stabilized steady state operation and a DAQ sampling rate of one measurement every 10 seconds
1 - Uniformity is defined as the maximum variance in temperature across all probes at any point in time over the testing period
2 - Stability is defined as the maximum variance in temperature experienced by any single probe over the testing period
Refrigeration System
| Component |
Specification |
| Compressor |
Variable speed (VSC), Refrigerator. Rated speed range: 1300-4000 rpm |
| Refrigerant |
R600a |
| Condenser |
Anti-fouling tube and grid design |
| Evaporator |
Fin and tube design, high efficiency fan |
| Defrost (Refrigerator/Freezer) |
Cycle Optimized Zero-Energy / Auto Defrost |
Controller, Configuration, Alarms and Monitoring
| Feature |
Description |
| Controller technology |
Individual XRi77CH microprocessor temperature controllers for both the refrigerator and freezer with digital temperature display, °C/°F switchable |
| Battery Backup |
12V high-capacity battery, controller, all alarms active, temperature monitoring DAQ and event logging active on battery backup |
| Display technology |
Bi-Colored LED display and alarm module with .1°C resolution, touchpad controls, resettable 1-point min/max history |
| Digital Communication |
RS-485 (MODBUS) |
| Adjustable Temperature Range (Refrigerator) |
1°C to 10°C |
| Adjustable Temperature Range (Freezer) |
-35°C to -15°C |
| External alarm connection |
State switching remote alarm contacts |
| Alarms |
Audible and visual high and low temperature alarms, refrigerator and freezer, 36 hour battery back-up on alarms, high/low temperature & loss of power, remote alarm contacts, door alarm |
| Controller probe |
2 probes for each chamber; 1 in air and 1 in sample bottle |
Electrical Specifications
| Parameter |
Specification |
| Rated Amperage |
3 Amps |
| Power Plug/Power Cord |
NEMA 5-15 Plug / Vaccine storage power cord warning label |
| Facility Electrical Requirement |
110-120V AC: 15 A (minimum) |
Dimensions
| Measurement |
Dimension (inches) |
| Exterior Width |
31" |
| Exterior Depth |
35 1/2" |
| Exterior Height |
76" |
| Interior Width - Top |
23 3/4" |
| Interior Width - Bottom |
26" |
| Interior Depth - Top |
13 1/4" |
| Interior Depth - Bottom |
19 3/4" |
| Interior Height |
52 5/8" |
| Total Open Depth |
62 1/4" |
| Door Swing |
32 1/2" |
Weight
| Type |
Weight (lbs) |
| Product Weight |
262 |
| Shipping Weight |
292 |
Certifications
ETL, C-ETL listed and certified to UL 471 Standard for Commercial Refrigerators and Freezers and CSA C22.2#120 Refrigeration Equipment
Warranty
- General warranty: Two (2) years parts and labor warranty
- Compressor warranty: Seven (7) years compressor warranty
Temperature Mapping Data
Refrigerator Temperature Probes (°C)
| Probe |
Ave |
Min |
Max |
| 1 |
4.8 |
5.6 |
4.3 |
| 2 |
4.8 |
5.5 |
4.4 |
| 3 |
4.9 |
5.4 |
4.4 |
| 4 |
4.9 |
5.5 |
4.5 |
| 5 |
4.8 |
5.3 |
4.5 |
| 6 |
4.7 |
5.4 |
4.4 |
| 7 |
5.1 |
5.5 |
4.7 |
| 8 |
5.0 |
5.5 |
4.7 |
| 9 |
4.9 |
5.5 |
4.4 |
| 10 |
4.9 |
5.4 |
4.5 |
| 11 |
5.1 |
5.7 |
4.7 |
| 12 |
4.9 |
5.6 |
4.6 |
| 13 |
5.1 |
5.6 |
4.7 |
| 14 |
5.1 |
5.6 |
4.7 |
| 15 |
5.0 |
5.4 |
4.6 |
Freezer Temperature Probes (°C)
| Probe |
Ave |
Min |
Max |
| 1 |
-30.7 |
-29.5 |
-32.1 |
| 2 |
-31.3 |
-30.0 |
-32.6 |
| 3 |
-31.6 |
-30.5 |
-32.7 |
| 4 |
-31.4 |
-30.3 |
-32.5 |
| 5 |
-31.5 |
-30.3 |
-32.6 |
| 6 |
-31.0 |
-30.0 |
-32.0 |
| 7 |
-31.3 |
-30.2 |
-32.3 |
| 8 |
-31.3 |
-30.2 |
-32.4 |
| 9 |
-31.0 |
-30.0 |
-32.0 |
| 10 |
-30.9 |
-29.9 |
-31.9 |
| 11 |
-30.7 |
-29.9 |
-31.9 |
| 12 |
-32.0 |
-30.4 |
-33.4 |
| 13 |
-31.5 |
-30.3 |
