Pharmaceutical Refrigerator / Freezer

This Pharmacy refrigerator and freezer combination unit is designed with a variable speed compressor to deliver unparalleled temperature control. Safeguard your samples with superior temperature uniformity and recovery, even after frequent door openings. Monitor your vaccines though intuitive digital displays and protective alarms.

SPECIFICATIONS:
Storage capacity (cu. ft): 13 Cu. Ft. Refrigerator / 3 Cu. Ft. Freezer
Door: Double Swing Solid Right Hinged Doors
Shelves (Frg/Frz): 3 adjustable, vented stainless steel shelves refrigerator / 1 fixed shelf freezer
Drawers (Frg/Frz): Non-applicable
Mounting and Installation: Leveling Legs
Interior lighting: 12V LED light bar (Refrigerator)
Airflow Management (Refrigerator): Forced draft air circulation (Refrigerator)
External probe access:Probe access port (3/8″) dia., 2 ea. (1 for Refrigerator/1 for Freezer)
Access control: Keyed door lock
General warranty: Two (2) years parts and labor warranty
Compressor warranty: Seven (7) years compressor warranty
Inside: top: 23.75W x 13.25"D x 14"H - Bottom 26"W x 19.75"D x 38"H
Outside: 31 x 35.5 x 76"H
Refrigerator Uniformity¹ (Cabinet air): +/-0.22°C
Refrigerator Stability² (Cabinet air): ±0.48°C
Refrigerator Maximum temperature variation: ±0.71°C
(Cabinet air)
Freezer Uniformity¹ (Cabinet air) ±0.69°C
Freezer Stability² (Cabinet air) ±1.14°C
Freezer Maximum temperature variation: ±1.95°C
(Cabinet air)
Energy Consumption (KWh/day): 3.73
Average Heat Rejection (BTU/hr): 5.25
Average Heat Rejection (BTU/hr): 746
Noise Pressure Level (dBA): 48 or less installed
Pull down time to nominal operating temp (Frg/Frz): 40 min / 165 min
Defrost (Refrigerator/Freezer): Cycle Optimized Zero-Energy / Auto Defrost
Controller technology: Individual microprocessor temp controllers for both refrigerator & freezer with digital temperature display, °C/°F switchable
Battery Backup: 12V high-capacity battery, controller, all alarms active, temperature monitoring DAQ and event logging active on battery backup
Display technology: Bi-Colored LED display and alarm module with .1°C resolution, touchpad controls, resettable 1-point min/max history
Digital Communication: RS-485 (MODBUS)
Calibration: Calibrated using a NIST traceable device, certificate included
Adjustable Temperature Range (Refrigerator): 1°C to 10°C
Adjustable Temperature Range (Freezer): -35°C to -15°C
External alarm connection: State switching remote alarm contacts
Alarms: Audible and visual high and low temperature alarms, refrigerator and freezer, 36 hour battery back-up on alarms, high/low temperature & loss of power, remote alarm contacts, door alarm
Controller probe: 2 probes for each chamber; 1 in air and 1 in sample bottle
