BYK-Gardner byko-test 4200 Fe (3634) Film Thickness Gauge

Condition: New Brand new item from stock or on order from manufacturer
1 YEAR MANUFACTURER'S WARRANTY
Stock #:
N1461
Dimensions (approx.):
4"W x 2.5"D x 1.1"H (outside)
Product Description
The byko-test 4500/4200 film thickness gauges allows for the measurement of a variety of products. No cable exchange or calibration is needed when changing from a ferrous to a non-ferrous substrate. The large LCD display and 10 second retention of the last measured value makes the byko-test 4500/4200 easy to use.

~ Compact pocket size instrument
~ One-handed design for ease of use
~ Switchable from mils to microns
~ Strong, wear resistant ruby probe tip
~ V-groove in probe for positioning on cylindrical parts
~ Acoustic signal for measurement confirmation
~ Automatic substrate recognition
~ Extended measuring range
~ Faster measuring speed
~ Graphic display with backlight
For sample areas that are difficult to reach, the byko-test 4500/4200 EC models come with an 1 meter length extension cable. The extension cable offers more flexibility to position the sensor

SPECIFICATIONS:
~ Substrate Fe: steel or iron
~ Substrate NFe: non-magnetic metals: aluminum, copper, brass, zinc, stainless steel
~ Measuring Range: Fe: 0 - 3000 ìm (0 - 120 mils) , NFe: 0 - 3000 ìm (0 - 120 mils)
~ Accuracy: ± (2µm + 3 %*)
~ Minimum Curvature: 5 mm (0.2 in) convex; 30 mm (1.2 in) concave
~ Minimum Substrate Thickness: Fe: 0.2 mm (0.01 in), NFe 0,05 mm (0,002 in)
~ Minimum Area of Measurement: 10 x 10 mm (0.4 x 0.4 in)
~ Power Supply 2 x AA Batteries
The following link provides additional information from the instruction manual or manufacturer's brochure. Click to open the PDF in a new window or right-click to download it:
BYK byko-test 4200 Fe (3634) Film Thickness Gauge or copy the following into your browser address window: labequip.com/stock/pictures/n1461.pdf
Made in Germany.
This item ships from Columbia, MD.
