Koehler HKV3000 High Temperature Kinematic Viscosity Bath with Integrated Digital Timing features for convenient, accurate glass capillary viscometry determinations.
Kinematic viscosity is of primary importance in the design and selection of a wide range of petroleum products. Calibrated capillary viscometers are used to measure flow under gravity or vacuum at precisely controlled temperatures. Microprocessor PID circuitry assures precise, reliable temperature control within ASTM specified tolerances throughout the operating range of the bath. Simple push-button controls and dual digital displays permit easy setting and monitoring of bath temperature. Two place calibration offset capability is provided. Baths accommodate seven glass capillary viscometers of various types. Viewing the viscometers is made easy by glare-free fluorescent illumination inside the bath and a baffle that provides a background for easy viewing. Temperature control uniformity is assured by means of motorized stirrer which provides complete circulation without turbulence. Connection of the built-in cooling coil to tap water or a recirculating water chiller facilitates temperature control at ambient or below ambient temperatures. Communications software (RS232, etc.) ramp-to-set, and other enhanced features are available at additional cost.
Integrated Timing Features _ HKV3000 incorporates seven digital timers on the front control panel for convenient timing and monitoring of the efflux interval for each viscometer. All timing functions are displayed in 0.01 second resolution and are accurate within 0.01%.
Bath Construction and Safety Features _ Bath chamber is a clear Pyrex vessel enclosed in a polyester-epoxy finished steel housing. Top working surface has seven 2" (51mm) viscometer ports and is constructed of stainless steel for easy cleaning. Front viewing window assures safe, distortion-free viewing. Microprocessor temperature controller incorporates safety circuitry that interrupts power to the heaters in the event of an over-temperature condition or disconnection of the primary probe. For added safety, a redundant adjustable controller with separate sensor probe interrupts power if an over-temperature situation occurs. An integrated low-liquid sensor prevents operation of the bath if the bath liquid is not filled to the proper level, and cuts off power should it fall below during operation. Both over-temperature and low liquid level circuits will latch and prevent further operation of the bath until the fault is removed. Bath rests on adjustable leveling feet. All electronics are mounted on a sliding tray for easy access. Includes thermometer holder and seven plastic port covers with handles.
Conforms to the specifications of: ASTM D445, D2170, D6074, D6158; IP 71, 319; ISO 3104; DIN 51550; FTM 791-305; NF T 60-100
Temperature Range: ambient to 232°C (450°F); -20°C to 232°C (-4°F to 450°F) with an external chiller
Temperature Control Display: 0.1°C/°F resolution, calibrate to 0.01°C/0.01°F
Temperature Control Accuracy and Uniformity: Exceeds ASTM requirements throughout the operating range
Integrated Timing: Seven individual start/stop timers with displays to 0.01 seconds, accurate to within 0.01%
Communication: RS232 port optional for HKV3000
Viscometer Ports: Seven round 2" (51mm) ports
Bath Medium: Water or suitable heat transfer fluid
Bath Capacity: 5.8 gal (22L)
Bath Depth: 12" (31cm)
Features and Benefits
- Microprocessor control of temperature between ambient and 232°C (450°F), and down to -20°C (-4°F) with an external chiller
- Integrated digital timing for convenient measurement of sample efflux times
- Dual digital displays show setpoint and actual bath temperature
- Selectable temperature scale - Fahrenheit or Celsius
- Integrated redundant over-temperature and low liquid level cut-off circuitry
- Conforms to ASTM D445, D2170 and related specifications for kinematic viscosity testing
The following link provides additional information from the instruction manual or original manufacturer's brochure. Right-click to open the PDF in a new window or download it: http://www.labequip.com/stock/pictures/n1200.pdf
